Technical Specifications
| Feature | Details |
| Material | Mild Steel / Carbon Steel (Grade 4.6 standard, Grade 8.8 available) |
| Standard Lengths | 1m, 2m, 3m sections — custom cutting available |
| Diameter Range | M6, M8, M10, M12, M16 (M20 available on request) |
| Thread Type | Fully threaded — Metric coarse thread (ISO 68-1 standard) |
| Thread Tolerance | Class 6g (medium fit) |
| Finish Options | • Electro-Galvanized (EG)<br>• Hot-Dip Galvanized (HDG)<br>• Plain (for indoor dry applications) |
| Compatibility | Standard hex nuts (DIN 934), lock washers, plate washers, couplers, beam clamps, strut clamps |
| Manufacturing | 100% automated production — Abu Rawash Industrial Zone, Giza |
| Quality Control | ISO 9001:2015 certified — batch testing for tensile strength |
Ordering Format: Specify Diameter + Length + Finish Example: M10 × 2000mm × HDG
Load Capacity & Design Reference
Safe working loads based on Grade 4.6 mild steel with 4:1 safety factor:
| Rod Diameter | Design Load (KG) | Tensile Strength | Typical Application |
| M6 | 459 kg | 12.3 kN | Light conduit & cable tray supports |
| M8 | 836 kg | 22.5 kN | Domestic & condensate piping |
| M10 | 1,335 kg | 35.9 kN | Standard HVAC hanger support |
| M12 | 1,937 kg | 52.1 kN | Heavy-duty pipe & equipment support |
| M16 | 3,598 kg | 96.8 kN | High-load riser mains & industrial racks |
| M20 | 5,617 kg | 151.2 kN | Process piping & structural applications |
Higher tensile grades (Grade 8.8) available for critical load applications. Contact our engineering team for custom load calculations.
Why New Age Threaded Rods?
100% Egyptian Automated Production
Unlike workshop fabrication, our CNC-controlled threading machinery ensures consistent thread precision, uniform dimensions, and zero defects—critical for system compatibility and safe load transfer. Every rod meets the exact specifications your engineer approved.
In-House Hot-Dip Galvanization
We control the entire galvanization process on-site at our Abu Rawash facility. No outsourcing means superior coating adhesion (minimum 85 microns), longer corrosion protection, and faster project turnaround. Our HDG finish meets ASTM A153 and is suitable for outdoor, humid, and coastal installations.
Controlled Steel Grade & Batch Testing
Every production batch undergoes tensile strength testing to verify load capacity. You get predictable, certified performance—not guesswork. Engineering load tables and test certificates available upon request for consultant approval.
Engineer-Level After-Sales Support
Direct access to our technical team for:
- Load capacity verification and rod sizing
- Compatibility guidance with anchor systems
- On-site installation support coordination
- Fast replacement for any specification or fit issues
Unlike traders who disappear after delivery, we stay with your project through completion.
Project-Ready Packaging & Availability
Rods arrive in protective bundles, labeled by size and finish—no site time wasted sorting bent or damaged inventory. With local stock in Giza and consistent production capacity, we support your project timeline without delays.
Product Range & Application Guide
Standard Sizes by System Type
| Rod Diameter | Common Application | Recommended For |
| M6 | Light electrical support | • Cable tray suspension (up to 150mm width)<br>• Conduit hangers<br>• Lighting fixtures |
| M8 | Small pipe suspension | • Domestic water lines (½” to 1″)<br>• Condensate drain piping<br>• Small HVAC branch lines |
| M10 | Standard MEP support | • Chilled water distribution (CHW)<br>• Hot water lines (HHW)<br>• Fire sprinkler branch lines<br>• Medium cable tray systems |
| M12 | Heavy mechanical systems | • Main HVAC risers<br>• Fire sprinkler mains<br>• Pump room equipment<br>• Large duct hangers |
| M16 | Industrial & high-load | • Process piping in industrial facilities<br>• Vertical riser mains<br>• Heavy equipment platforms<br>• Seismic-rated installations |
Suspension & Fastening Applications
New Age Threaded Rods are used as the primary vertical load-transfer element in:
Mechanical Piping Systems
- Chilled water (CHW) and hot water (HHW) distribution networks
- Condenser water lines
- Vertical and horizontal pipe hanger assemblies
- Equipment vibration isolation mounts
Fire Protection Systems
- Sprinkler main risers and distribution racks
- Pre-action and deluge system supports
- Fire pump room installations
- Seismic bracing for firefighting lines
Electrical Support Systems
- Cable tray and raceway suspension
- Busway and conduit hangers
- Lighting fixture and equipment racks
- Transformer and switchgear anchoring
Industrial & Factory Installations
- Machine platform supports
- Conveyor and material handling systems
- Service platform structures
- Process equipment suspension
Finish Selection Guide
Choose the right finish based on your installation environment:
| Finish Type | Best For | Corrosion Resistance | Lead Time |
| Hot-Dip Galvanized (HDG) | Outdoor installations<br>Plant rooms<br>Coastal areas<br>High humidity zones | Excellent (15-20 years typical) | Standard stock |
| Electro-Galvanized (EG) | Indoor dry installations<br>Electrical systems<br>Conditioned spaces | Good (5-10 years typical) | Standard stock |
| Plain (Uncoated) | Temporary supports<br>Indoor dry only<br>Cost-sensitive projects | Minimal | Fast delivery |
Most Specified: Hot-Dip Galvanized for HVAC, firefighting, and outdoor MEP systems.
Proven Performance on Major Projects
New Age Threaded Rods have been specified and installed in:
✓ Opera House Rehabilitation Project — Complete MEP support systems
✓ Military Complex Infrastructure — Firefighting and mechanical installations
✓ New Giza Development (Phases 2-4) — Residential and commercial MEP
✓ 205 Project, Sheikh Zayed — Recommended by consulting engineer
✓ Multiple Government & Private Developments — Across Greater Cairo and Upper Egypt
Trusted by Egypt’s top contractors: Orascom Construction, Hassan Allam, and leading MEP subcontractors.
→ Request Project References & Engineer Testimonials
Installation Guidelines
Structural Requirements
- Verify rod tensile capacity is adequate for total pipe weight + fluid load + safety factor (minimum 4:1)
- Select anchor bolt or beam clamp that matches rod diameter and structural member capacity
- Ensure structural support (concrete slab, steel beam) can handle the imposed load
Installation Procedure
- Anchor Installation: Secure rod to structural support using appropriate anchor bolt, expansion anchor, or beam clamp
- Vertical Alignment: Level and adjust rod height for consistent alignment across the support run
- Hanger Connection: Attach pipe hanger, strut bracket, or equipment support to rod using hex nuts and washers
- Load Transfer: Position pipe or equipment and secure final assembly
- Locking: Apply lock nuts or lock washers where vibration or thermal movement is expected
Installation Support Available: Our engineering team can coordinate with your site MEP contractor for proper sizing, spacing, and installation verification.
Standards & Compliance
New Age Threaded Rods are manufactured and tested in accordance with:
- ISO 68-1 — Metric thread profile and dimensions
- ISO 898-1 — Mechanical properties of carbon steel fasteners
- ASTM A153 — Hot-dip galvanization specification
- ASTM B633 — Electro-galvanization requirements
- Egyptian Mechanical Code — Pipe support spacing and load requirements
- ISO 9001:2015 — Quality management system (Factory certified)
Test certificates, material certifications, and engineering load tables available for consultant approval and submittal packages.
Technical Support & Engineering Services
Our team provides:
- Load & Spacing Recommendations — Based on Egyptian Mechanical Code requirements
- Rod Diameter Selection — Verified calculations for your system weight and configuration
- Beam Clamp & Anchor Compatibility — Guidance on complete support assembly
- On-Site Coordination — Support meetings with your MEP contractor when needed
- Submittal Package Preparation — Technical data sheets, certificates, and test reports for consultant approval
Direct access to engineers who understand your project challenges—not just sales representatives.
